RDL RU-TPS4A DISTRIBUTION UNIT Active, 3x terminal block inputs, 4x Format-A RJ45 outputs

Artikelnummer
57-4809
Hersteller
RDL (Radio Design Labs)
Typennummer
  • RU-TPS4A
RDL RU-TPS4A DISTRIBUTION UNIT Active, 3x terminal block inputs, 4x Format-A RJ45 outputs
RDL RU-TPS4A DISTRIBUTION UNIT Active, 3x terminal block inputs, 4x Format-A RJ45 outputs

RDL AV INTERFACES - RACK-UP Series

RDL Rack-Up series are 1/3 rack-width, rack-mounting modules, 1U high, offered with a wide range of functionality. Some Rack-Up modules are constructed in solid, encapsulated, durable, industrial, black plastic enclosures; Max Rack-Ups are assembled using heavy-duty, extruded-aluminium and steel panels. The rear panels have 'clear bold white lettering' for the terminal blocks and connectors. Reverse-printed, front-panel, poly-carbonate laminates provide a durable finished appearance for rack-mounted or free-standing use. Certain Rack-Up modules are often used free-standing; all Rack-Ups may be rack mounted by means of a range of mounting options, listed within this group.

DANTE INTERFACES - Format-A - Input

DANTE INTERFACES - Format-A - Output

DANTE INTERFACES - Output

DANTE INTERFACES - Format-A - Bi-directional

DANTE INTERFACES - Terminal block - Bi-directional

AUDIO DISTRIBUTION – Format-A


RU-TPS4A

This active audio sender and distribution module has three balanced or unbalanced line-level inputs on screw terminal connections, along with four outputs on RJ45 connections with Format-A compatibility. Front panel LEDs indicate the levels of each input pair whilst a blue LED to the bottom right of the front panel signifies 24Vdc power. Green LEDs positioned on the rear panel illuminate when the correct output voltage is sensed on the RJ45 connections.

MIXERS - DANTE

MIXERS - Analogue

ATTENUATORS

DISTRIBUTION AMPLIFIERS

POWER AMPLIFIERS

HEADPHONE AMPLIFIERS

PREAMPLIFIERS

EQUALISERS

AUDIO METERS

SWITCHERS

SEQUENCING CONTROLLERS

CONVERTERS

Powering

Powering: All units require a 24V DC power supply; each has both screw terminals and coaxial socket for power input. A ‘universal’ supply is available, 57-401, with 24V 3A output, which requires an IEC cord set. See RDL POWER SUPPLIES for more details. Note that all RDL modules with co-axial power input/output sockets use connectors with 2.5mm pins.
