Designation denotes configuration of adapter contacts. All adapters are supplied pre-wired. 49-219 has “phase reverse” legend engraved in red. 49-200 is XLR male/female unwired, for user’s specially wired applications.
Wiring conventions
Terminology used in adapter descriptions
3FX |
3 pin female XLR |
3MX |
3 pin male XLR |
2P |
2 pole 6.35mm jack plug |
2JA |
2 pole 6.35mm A-gauge jack socket |
3P |
3 pole 6.35mm A-gauge jack plug |
3J |
3 pole 6.35mm jack socket (accepts both A and B gauge plugs) |
3JA |
3 pole 6.35mm jack socket (accepts A gauge plugs only) |
PHM |
RCA (Phono) male |
PHF |
RCA (Phono) female |
BNCF |
BNC socket |
BNCM |
BNC plug |
3MJS |
3 pole mini jack (3.5mm) socket |
3MJP |
3 pole mini jack (3.5mm) plug |
NLF |
4 pole speakon plug |
5FX |
5 pin female XLR |
5MX |
5 pin male XLR |
