SHURE P9T PERSONAL MONITOR TRANSMITTER Fixed, 656-692MHz (L6E)

Shure PSM 300 stereo personal monitoring system delivers 24-bit digital audio processing and allows wireless transmission and reception up to 90m, of audio monitoring to musicians, singers, and presenters. PSM 300 offers custom control of a personal mix from two channels of audio whilst up to 15-channels and up to 24MHz of tuning bandwidth are accessible using pre-programmed groups and channels.

System Bundles

P3T - Transmitter

This half-width rackmount transmitter is included in all PSM 300 systems and has dual, electronically balanced, 6.35mm 3-pole jack inputs and loop outputs of the same specification. All connections are on the rear panel as well as a 'StereoMX/Mono' switch, which can be set to send either a two-channel stereo mix or summed audio mix to the P3R/P3RA receiver and a 'Line/Aux' switch switches the input sensitivity between -10dBv (Aux) and +4dBu (line) to suit the source device. There is a single BNC connector for use with removable antenna, and a power adapter input for the included PSU. The front panel has an LCD display to show current status and settings menu, a 'Sync' button to allow synchronised setup via infrared, group and channel buttons, power on/off switch, and a rotary control to adjust the audio input level.

Nominal input level: +4dBu/-10dBv, switchable. RF output power: 10/20/30mW, country dependant. Power source: 12-15V DC, 260 mA maximum. Dimensions (WxDxH): 198 x 172 x 43mm. Weight: 783g.

Included accessories: AC Adapter, quarter wave antenna, rack mounting kit, user guide.

P3R - Receiver, bodypack, ABS plastic

This belt-pack receiver is included in the 74-5994 system and is manufactured from moulded ABS to result in a lightweight and cost effective solution. A fixed antenna is positioned on the top panel alongside a rotary volume control/power control, 3.5mm stereo jack headphone output and LEDs to indicate power and RF activity. The MixMode rotary control is positioned on the side of the unit. All other controls and displays are hidden behind the battery compartment door. Here there are buttons to adjust the channel, group and perform a scan, along with a single-digit display to show the current setting. On the rear of the unit there is belt clip.

Battery life: 7 hours. RF sensitivity: 2.2uV at 20dB SINAD dBm, for 12cV SINAD, typical. Audio output power: 40mW. Load impedance: 4ohms minimum. Power source: 2x AA alkaline cells. Dimensions (HxWxD): 110 x 64 x 21mm. Weight: 98g, less battery.

P3RA - Receiver, bodypack, metal

This has the functionality of the P3R but is housed within a smaller metal body for a more robust and compact solution. Additional features of the P3RA include 2-band shelving EQ, battery display in hours and minutes, an LCD screen with menu based setting adjustment and compatibility with the SB900-B battery.

Battery life: 7 hours. RF sensitivity: 2.2uV at 20dB SINAD dBm, for 12cV SINAD, typical. Audio output power: 80mW. Load impedance: 16 ohms minimum. Power source: 2x AA alkaline cells or SB900-B. Dimensions (HxWxD): 110 x 64 x 21mm. Weight: 196g, less battery.

Shure PSM 1000 series is very similar to PSM 900 series, however PSM 1000 series offers an increased number of compatible frequencies, diversity reception and software control over a network. PSM 1000 components are audio and frequency-sync compatible with PSM 900 series (depending on tuning bandwidth), and the transmitters are also compatible with the UHF-R series of radiomic receivers, so can be used for point-to point links. The receivers use AA cells or optional SB900-B battery pack, and may be charged in the SBC200 or SBC800 charger, without removing the battery from the receiver.

PSM 900 vs PSM 1000

P10T - Transmitter

Containing two transmitters, the P10T takes up the full width of a 19 inch rack, and is supplied ready for rack mounting. The rack ears are punched to take extension cables when front mounting the antenna. The interactive menu system allows the setting of RF group, channel, frequency, RF power, stereo/mono/point-to-point (with a UHF-R receiver, which requires pilot tone) transmission, +4dBu/-10dBV input level. Utility settings include: Name of transmission (uploaded to body pack with Sync), display format, brightness and contrast, control locking options, network set up. Sent to body pack with Sync: Body pack lock, volume limiter, stereo/mono, mixed mode/stereo mode, high frequency boost.

An Ethernet connection may be used to connect the P10T transmitter to a standard Ethernet network using switches and either DHCP or fixed manual IP addresses; the second Ethernet connection is effectively the second output of an Ethernet hub, so may be used to loop out to the Ethernet connection of the next P10T. The Wireless Workbench software-based tool for advanced set-up, control, and monitoring may be downloaded freely from www.shure.com. The transmitter may be controlled by an AMX or Crestron system over Ethernet.

The front panel has two sets of: Input level control; up/down buttons, LED bargraphs, clip LED. Status display and menu operation; LCD display with navigation buttons. RF switch. RF LED. In addition there are shared enter and exit buttons and menu wheel. Synchronisation; an IR sensor window. Headphone monitoring; 3.5mm stereo jack socket, rotary volume control with push function to switch between transmitters. Power button.
Rear panel: Powering; AC primary power switch, IEC inlet, IEC loop-out outlet. For each of the two transmitters: Two balanced audio input connectors, combination XLR and 6.35mm jack; two balanced loop out connectors, 6.35mm jack; 1x antenna connector, BNC. In addition there are two RJ45 Ethernet network connectors.

Inputs: +4dBu or -10dBV, 70k ohms, nominal; +29dBu or +12 dBu maximum. Audio outputs: connected directly to inputs. Power source: 100-240V AC, 50/60 Hz, 0.5A maximum. Loop out: 5A maximum, un-switched. Dimensions (WxDxH): 483 x 343 x 44mm, 1U rack mounting. Weight: 4.7kg.

Included accessories: 2x antenna. Rack-mounting screws, antenna hole plugs. IEC power cable, IEC-IEC link cable. Ethernet cable. 2x antenna extension cables for mounting the antennae on the front.

P10R+ - Receiver, bodypack

The P10R+ body-pack or belt-pack receiver has two external whip antennas and a belt clip. The interactive menu system allows the setting of functions including RF group, channel, frequency, squelch, Stereo/Mixmode audio, HF audio boost, and level limit value. Utility settings include: CueMode on off, display format and contrast, panel lock. P10R+ offers three types of frequency scan; 'Channel scan' finds the first available channel; 'Group scan' finds the group with the largest number of available channels; and 'Full scan' performs a spectrum scan and displays the results in a graphical interface.

Upper panel: Power switch/volume rotary control, two SMA antenna connectors, a 3.5mm stereo jack earphone socket, and LED indicators for battery power and RF received. Front panel: LCD display to show current status and menu operation, and up/down buttons. Inside battery compartment are enter and exit buttons, sync IR window and scan button. Space for 2x AA batteries or battery pack. Rear: Belt clip

Included accessories: 2x AA batteries, 2x whip antennae.

Axient Digital PSM series in ear monitoring systems have been designed for the most professional and demanding live musician monitoring and broadcast IFB.

ADTD - Dual transmitter

ADTD wireless dual in-ear monitoring transmitter has a host of features including scalable channel count, multichannel wideband RF, and spatial diversity transmission. This ensures the transmitter can perform in the most challenging RF environments. ShowLink remote control, networkable monitoring with Wireless Workbench, analogue and digital inputs, and internal antenna combining, allow a greater level of management and flexibility to the in-ear monitor system workflow. Note, some of the listed features will be available in planned firmware updates.

The front facing panel hosts a large, 6.6-inch colour display, allowing the user to see and navigate menu items and working statuses at a glance. To the right of the screen, four function buttons along with enter button and exit button allow navigation of menus and settings. A large push jog wheel assists in navigation, value changes, and selection. A 3.5mm stereo headphone jack connector allows local monitoring of audio, whilst an associated rotary controller allows for volume changes. An infrared sensor syncs a receiver with data settings required, and a RF switch allows the user to quickly mute transmission. A main power on/off switch is positioned to the far right of the transmitter.

The rear facing panel houses BNC connections for A and B external antenna, combination 6.35mm/3-pin XLR inputs for channels 1-4, and four RJ45 connections for control 1, 2, and Dante ports 1 and 2. A switch allows the user to select between analogue and AES3 inputs. For models with redundant DC power, the power is via a single AC IEC input connection, and a single DC power input. For models without redundant powering, a single AC IEC input is positioned next to a female AC IEC thru connection for linking to multiple transmitters in a chain.

Versions available

Included accessories: 1x rackmount kit. 2x BNC cables, 2x BNC cable assemblies, 2x BNC bulkhead adapters, 2x half-wave antennas, 1x Ethernet cable, 1x Ethernet jumper cable
Optional accessories: AD221 antenna combiner, AD221X antenna combiner, AD8C antenna combiner.

ADTQ - Quad transmitter

ADTQ follows the same technology and feature set as ADTD, however the 1U rackmount transmitter has four channels of transmission, therefore all I/O connectivity is twice that of ADTD - with the exception of the control, Dante, and power connectors which remain as either AC in/thru or AC/DC redundant inputs.

Versions available

Included accessories: 1x rackmount kit. 2x BNC cables, 2x BNC cable assemblies, 2x BNC bulkhead adapters, 1x Ethernet cable, 1x Ethernet jumper cable
Optional accessories: AD221 antenna combiner, AD221X antenna combiner, AD8C antenna combiner.

ADXR - Receiver

Compatible with the Axient Digital PSM ADTQ and ADTD wireless transmitters, ADXR wireless bodypack receiver for Axient Digital PSM delivers the 'highest quality' personal monitoring experience for performances on stage, tv, or event. Features include true digital diversity that combines two discrete RF signals for greater RF quality and range; ShowLink that provides engineers with comprehensive real-time remote control of all the ADXR parameters; and CueMode that allows engineers to easily monitor up to 64 encrypted stage mixes from a single pack. Stereo separation and automatic impedance detection allow ADXR to pair with most professional in-ear monitors, such as Shure's SE range. The casing is manufactured from durable, moisture-resistant, and lightweight hybrid aluminium/polymer enclosure, and it employs a threaded headphone connector for added protection against sweat and moisture

The front facing side of the receiver bodypack features a screen to display channel, frequency, audio reception, signal reception, name, and battery life among other values. There is also a battery compartment door which also allows access to four menu selection/navigation buttons. The rear facing side has a belt clip and external charging contacts for convenient docked charging. The upper edge of the receiver has 2x BNC connectors for the antenna, a 3.5mm stereo jack headphone output with associated rotary volume control, and LEDs to signify RF and battery status.

Versions available

Included accessories: 2x SB910 rechargeable Lithium-Ion batteries, 2x whip antennas, 1x zippered carry bag.
Optional accessories: SBC441 4-way charger, SBC441UK 4-way charger with UK power supply.
